Ball valve 3 piece body XS carbon steel/RTFE Butt Weld
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
Butt weld
PTFE
| Model: | 3 piece body | Material body: | Carbon steel 1.0619 |
| Connection: | Butt weld | Material ball: | Stainless steel CF8M |
| Temperature: | -25°C / +220°C | Material seat: | PTFE+50% Stainless steel |
| Pressure: | 63 bar check PDF | Steam: | Up to 15 bar max.200°C |
Datasheet (PDF)
| SKU | MXT-738X272600 |
|---|
| Body material | Steel 1.0619 |
|---|---|
| Disc / Ball / Wedge | Stainless steel-CF8M-316 |
| Seat | PTFE+50%St.St |
