Ball valve pneumatic actuator spring return Stain.St/PTFE PN16
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
PTFE
DIN
| Model: | 2 piece body | Material body: | Stainless steel CF8M |
| Connection: | Flanged PN16 | Material disk: | Stainless steel 316 |
| Pressure: | 16 bar | Material seat: | PTFE |
| Temperature: | -20°C / 70°C | Operation: | Pneumatic spring return |
Datasheet (PDF)
| SKU | MXT-763SA0000 |
|---|
| Body material | Stainless.steel-CF8M |
|---|---|
| Disc / Ball / Wedge | Stainless steel-CF8M-316 |
| Seat | PTFE |
