Ball valve spring return deadman handle - stainless steel - thread BSP
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
BSP
PTFE
| Model: | Spring closed | Material body: | Stainless steel CF8M-1.4408 |
| Connection: | Thread BSP | Material ball: | Stainless steel CF8M-1.4408 |
| Actuating: | Deadman handle | Material seat: | PTFE |
| Approved: | ATEX | Material handle: | Stainless steel AISI 304 |
| Pressure: | 63 bar | Temperature: | -20°C to +200°C |
Datasheet (PDF)
| SKU | MXT-2006003000 |
|---|
| Body material | Stainless steel ASTM A351 CF8M-316 |
|---|---|
| Disc / Ball / Wedge | SS ASTM A351 CF8M-SS316 |
| Seat | PTFE |
