Butterfly valve Sylax wafer lever GG25/St.St/EPDM PN6/10/16
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
EPDM
| Model: | Wafer type with lever | Material body: | Cast iron GG25 |
| Connection: | Between flanges PN6/10/16 ANSI150# | Material Disc: | Stainless steel 316 |
| Pressure: | 16 bar | Material seat: | EPDM |
| Temperature: | -10°C +120°C check technical PDF | Operation: | Lever |
| Kiwa approval |
| Use: Maritime systems, seawater, ballast systems, engine rooms, lens systems, |
Datasheet (PDF)
| SKU | MXT-5720967000 |
|---|
| Body material | Cast Iron-GG25-EN-GJL-250 |
|---|---|
| Disc / Ball / Wedge | StainlessSteel-1.4408-316 |
| Seat | EPDM |
