Butterfly valve wafer pneumatic actuator double acting-GG25-Stainl.St.-EPDM

EPDM
Butterfly valve wafer pneumatic actuator double acting-GG25-Stainl.St.-EPDM

Pneumatic actuator information:
Double acting model
EN 15714-3 certified - ATEX EEx II 2G/D c for areas 1, 2, 21 & 22
Valve mounting according to ISO 5211
Limit switch box bracket connection & solenoid pilot valve connection according to NAMUR VDI/VDE 3845
Rack and pinion actuator - 90° operating angle (±5°)
Anodized aluminum body - Epoxy coated aluminium caps
Position indicator - Adustable limits screws
Environment working temperature: -30°C/+100°C - Max. air supply: 8 bar - Air supply connection 1/4".

Butterly valve information:
GG25 body
CF8M disc
EPDM seat
Wafer type PN10/16 & ANSI 150
PS: 16 bar
TS: -10°C/+110°C.

Body material Cast Iron-GG25-EN-GJL-250
Disc / Ball / Wedge Stainless steel-CF8M-316
Seat EPDM
pzh ce iso9001
32-40
33
€238.42
Qty
minus-sm
plus-sm
50
43
€239.63
Qty
minus-sm
plus-sm
65
46
€271.93
Qty
minus-sm
plus-sm
80
46
€280.88
Qty
minus-sm
plus-sm
100
52
€340.03
Qty
minus-sm
plus-sm
125
56
€377.74
Qty
minus-sm
plus-sm
150
56
€464.35
Qty
minus-sm
plus-sm
200
60
€669.61
Qty
minus-sm
plus-sm
250
68
€1,253.62
Qty
minus-sm
plus-sm
250
78
€1,525.73
Qty
minus-sm
plus-sm
