Check valve swing type thread BSP brass PN10

Model: Swing check Material body: Brass CW 617 N
Connection: Thread BSP Material disc: Brass CW 617 N
Pressure: PN10 Material seat: 3/8" to 2" EPDM 2.1/2" to 4" NBR
Temperature: + 0°C  + 60°C Material bonnet: Brass CW 617 N

The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.

SKU: MXT-3020881000
Body material Brass-CW617N
Disc / Ball / Wedge Brass-CW617N
Seat Rubber EPDM/NBR
View products
Grouped product items
SKU Product Name DN Length € / st Qty
MXT-3020881010 Check valve swing type thread BSP brass PN10-3/8'' 3/8" 47
€4.03
- +
MXT-3020881015 Check valve swing type thread BSP brass PN10-1/2'' 1/2" 47
€4.75
- +
MXT-3020881020 Check valve swing type thread BSP brass PN10-3/4'' 3/4" 53
€6.75
- +
MXT-3020881025 Check valve swing type thread BSP brass PN10-1'' 1" 63
€11.49
- +
MXT-3020881032 Check valve swing type thread BSP brass PN10-1.1/4'' 1.1/4" 70
€14.77
- +
MXT-3020881040 Check valve swing type thread BSP brass PN10-1.1/2'' 1.1/2" 88
€25.96
- +
MXT-3020881050 Check valve swing type thread BSP brass PN10-2'' 2" 97
€35.60
- +
MXT-3020881065 Check valve swing type thread BSP brass PN10-2.1/2'' 2.1/2" 116
€94.75
- +
MXT-3020881080 Check valve swing type thread BSP brass PN10-3'' 3" 135
€126.93
- +
MXT-3020881100 Check valve swing type thread BSP brass PN10-4'' 4" 164
€204.83
- +
