Gearbox Rotork cast iron AB880N - IP67 - torque 2000NM
The shown images can differ from the actual product. Technical data & prices are subjected to be changed without prior notice.
Gearbox cast iron with flat indicator
pipe steel handwheel ( option) see order line
Suitable for butterfly valves and quarter-turn valves.
Due to its strong robust design suitable for heavy duty.
Housing sealed to IP67 protection class
This type is suitable for outdoor installation.
Adjustable through integrated end stops.
Shaft of stainless steel.
Max torque: 2000 Nm
Mounting flange size according to ISO 5211: F12 / F16 of F10 / F14
Suitable for shaft in square and 45 degree position set easily by a double keyway.
| SKU | MXT-4025AB880N |
|---|
| Body material | GG25 cast iron |
|---|---|
| Disc / Ball / Wedge | Ductile-GGG40 |
| Seat | Nylon |
